SDI90B-16-TC-P11 _ AC DC Desktop, Wall Power Adapters_Power Supplies

Part Number	SDI90B-16-TC-P11
Manufacturer	CUI Inc
Other Part Numbers	102-SDI90B-16-TC-P11-ND 102-SDI90B-16-TC-P11
Description	AC-DC, 16 VDC, 5.63A, SW, C6 DES
Detailed Description	16V 90 W AC/DC External Wall Mount (Class II) Adapter Fixed Blade Input
Manufacturer Standard Lead Time	21 weeks
Datasheet	Datasheet

Category		Power Supplies - External/Internal (Off-Board) AC DC Desktop, Wall Power Adapters
Manufacturer		CUI Inc
Series		SDI90B-T (90W)
Packaging		Box
Part Status		Active
Size / Dimension		5.26" L x 2.11" W x 1.30" H (133.5mm x 53.5mm x 33.0mm)
Voltage - Output		16V
Polarization		Positive Center
Output Connector		Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 9.5mm
Voltage - Input		90 ~ 264 VAC
Cord Length		47" (1.20m)
Operating Temperature		-20°C ~ 40°C
Applications		ITE (Commercial)
Input Type		Fixed Blade
Approval Agency		CE, cULus, FCC, PSE, UKCA
Form		Wall Mount (Class II)
Efficiency		Level VI
Current - Output (Max)		5.63A
Input Connector		NEMA 1-15P
Region Utilized		North America
No Load Power Consumption		210mW
Power (Watts)		90 W
Standard Number		62368-1

RESOURCE TYPE		LINK
Datasheets		SDI90B-16-TC-P11

ATTRIBUTE		DESCRIPTION
Moisture Sensitivity Level (MSL)		1 (Unlimited)
RoHS Status		ROHS3 Compliant
