Part Number	SN54S64J
Manufacturer	Texas Instruments
Other Part Numbers	296-SN54S64J-ND 296-SN54S64J
Description	4-2-3-2 INPUT AND-OR-INVERT GATE
Detailed Description	AND/OR/INVERT Gate Configurable 1 Circuit 11 Input (4, 2, 3, 2) Input 14-CDIP
Datasheet	Datasheet

Product Attributes

Category		Integrated Circuits (ICs) Logic Gates and Inverters - Multi-Function, Configurable
Manufacturer		Texas Instruments
Series		54S
Packaging		Tube
Part Status		Active
Package / Case		14-CDIP (0.300", 7.62mm)
Output Type		Single-Ended
Mounting Type		Through Hole
Logic Type		AND/OR/INVERT Gate
Operating Temperature		-55°C ~ 125°C
Voltage - Supply		4.5V ~ 5.5V
Current - Output High, Low		20mA, 1mA
Number of Inputs		11 Input (4, 2, 3, 2)
Schmitt Trigger Input		No
Supplier Device Package		14-CDIP
Number of Circuits		1

Documents & Media

RESOURCE TYPE		LINK
Datasheets		SN54S64J

Environmental & Export Classifications

ATTRIBUTE		DESCRIPTION
Moisture Sensitivity Level (MSL)		Not Applicable
RoHS Status		ROHS3 Compliant
