SSR1N60BTM _ Single FETs, MOSFETs_FETs, MOSFETs_Transistors_Discrete Semiconductor Products

Part Number	SSR1N60BTM
Manufacturer	Fairchild Semiconductor
Other Part Numbers	2156-SSR1N60BTM-FSTR-ND FAIFSCSSR1N60BTM 2156-SSR1N60BTM-FSTR
Description	MOSFET N-CH 600V 900MA DPAK
Detailed Description	N-Channel 600 V 900mA (Tc) 2.5W (Ta), 28W (Tc) Surface Mount TO-252 (DPAK)

Category		Discrete Semiconductor Products Transistors FETs, MOSFETs Single FETs, MOSFETs
Manufacturer		Fairchild Semiconductor
Series
Packaging		Bulk
Part Status		Obsolete
Package / Case		TO-252-3, DPAK (2 Leads + Tab), SC-63
Mounting Type		Surface Mount
Operating Temperature		-55°C ~ 150°C (TJ)
Technology		MOSFET (Metal Oxide)
FET Type		N-Channel
Current - Continuous Drain (Id) @ 25°C		900mA (Tc)
Rds On (Max) @ Id, Vgs		12Ohm @ 450mA, 10V
Power Dissipation (Max)		2.5W (Ta), 28W (Tc)
Vgs(th) (Max) @ Id		4V @ 250µA
Supplier Device Package		TO-252 (DPAK)
Drive Voltage (Max Rds On, Min Rds On)		10V
Vgs (Max)		±30V
Drain to Source Voltage (Vdss)		600 V
Gate Charge (Qg) (Max) @ Vgs		7.7 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds		215 pF @ 25 V

RESOURCE TYPE		LINK

This product is no longer manufactured.
