Part Number	UCC3813PW-1
Manufacturer	Unitrode
Other Part Numbers	2156-UCC3813PW-1-ND TEXUNIUCC3813PW-1 2156-UCC3813PW-1
Description	UCC3813-1 LOW POWER ECONOMY BICM
Detailed Description	Boost, Flyback, Forward Converter Regulator Positive Output Step-Up, Step-Up/Step-Down DC-DC Controller IC 8-TSSOP
Datasheet	Datasheet

Category		Integrated Circuits (ICs) Power Management (PMIC) DC DC Switching Controllers
Manufacturer		Unitrode
Series
Packaging		Bulk
Part Status		Active
Package / Case		8-TSSOP (0.173", 4.40mm Width)
Output Type		Transistor Driver
Mounting Type		Surface Mount
Function		Step-Up, Step-Up/Step-Down
Operating Temperature		0°C ~ 70°C (TA)
Output Configuration		Positive
Frequency - Switching		46kHz
Topology		Boost, Flyback, Forward Converter
Voltage - Supply (Vcc/Vdd)		7.4V ~ 12V
Supplier Device Package		8-TSSOP
Synchronous Rectifier		No
Control Features		Frequency Control
Output Phases		1
Duty Cycle (Max)		49%
Clock Sync		No
Number of Outputs		1
