Part Number	UCC5320SCDWVR
Manufacturer	Texas Instruments
Other Part Numbers	296-52203-2-ND 296-52203-1-ND 296-52203-6-ND 296-52203-2 296-52203-1 UCC5320SCDWVR-ND 296-52203-6
Description	DGTL ISO 3KV 1CH GATE DVR 8SOIC
Detailed Description	4.3A Gate Driver Capacitive Coupling 3000Vrms 1 Channel 8-SOIC
Manufacturer Standard Lead Time	6 weeks
Datasheet	Datasheet

Category		Isolators Isolators - Gate Drivers
Manufacturer		Texas Instruments
Series
Packaging		Tape & Reel (TR) Cut Tape (CT)
Part Status		Active
Package / Case		8-SOIC (0.295", 7.50mm Width)
Mounting Type		Surface Mount
Operating Temperature		-40°C ~ 125°C
Current - Peak Output		4.3A
Technology		Capacitive Coupling
Current - Output High, Low		2.4A, 2.2A
Voltage - Isolation		3000Vrms
Approval Agency		CQC, UR, VDE
Supplier Device Package		8-SOIC
Rise / Fall Time (Typ)		12ns, 10ns
Common Mode Transient Immunity (Min)		100kV/µs
Propagation Delay tpLH / tpHL (Max)		75ns, 75ns
Pulse Width Distortion (Max)		20ns
Number of Channels		1
Voltage - Output Supply		13.2V ~ 33V

RESOURCE TYPE		LINK
Datasheets		UCC5310/UCC5320/UCC5350/UCC5390 08/Jan/2019
Datasheets		Mult Dev Material Chg 8/Jul/2021
Datasheets		Marking Standardization 18/May/2023

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8542.39.0001
Moisture Sensitivity Level (MSL)		2 (1 Year)
REACH Status		REACH Unaffected
RoHS Status		ROHS3 Compliant
