Category | | |
Manufacturer | | CUI Inc |
Series | | VF-S320 (320W) |
Packaging | | Box |
Part Status | | Not For New Designs |
Power (Watts) | |
320W
|
Features | |
Adjustable Output, PFC, Universal Input
|
Size / Dimension | |
6.00" L x 4.00" W x 1.50" H (152.4mm x 101.6mm x 38.1mm)
|
Mounting Type | |
Chassis Mount
|
Voltage - Input | |
90 ~ 132 VAC, 180 ~ 264 VAC
|
Type | |
Open Frame
|
Operating Temperature | |
0°C ~ 70°C (With Derating)
|
Applications | |
ITE (Commercial)
|
Approval Agency | |
CB Scheme, EN, IEC, SIQ, TUV, UL
|
Efficiency | |
83%
|
Voltage - Output 1 | |
24V
|
Number of Outputs | |
1
|
Voltage - Isolation | |
3 kV
|
Standard Number | |
55024; 55032 Class B; 61000-3-2; 61000-3-3; 62368-1
|
Current - Output 1 | |
7.5 A
|
---|
