W2F15C1038AT1F _ Feed Through Capacitors_Filters_

+86-0755-8325-4547

W2F15C1038AT1F

Part Number	W2F15C1038AT1F
Manufacturer	KYOCERA AVX
Other Part Numbers	478-2235-2-ND 478-2235-1-ND 478-2235-6-ND 478-2235-6 478-2235-2 478-2235-1
Description	CAP FEEDTHRU 0.01UF 50V 0805
Detailed Description	10000 pF Feed Through Capacitor 50V 300 mA 600mOhm 0805 (2012 Metric), 4 PC Pad
Manufacturer Standard Lead Time	14 weeks

Product Attributes

Category		Filters Feed Through Capacitors
Manufacturer		KYOCERA AVX
Series		W2F
Packaging		Tape & Reel (TR) Cut Tape (CT)
Part Status		Active
Tolerance		-20%, +50%
Voltage - Rated		50V
Package / Case		0805 (2012 Metric), 4 PC Pad
Temperature Coefficient		X7R
Size / Dimension		0.079" L x 0.049" W (2.01mm x 1.25mm)
Mounting Type		Surface Mount
Operating Temperature		-55°C ~ 125°C
Height (Max)		0.045" (1.14mm)
DC Resistance (DCR) (Max)		600mOhm
Capacitance		10000 pF
Current		300 mA

Documents & Media

RESOURCE TYPE		LINK

Environmental & Export Classifications

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8532.24.0020
Moisture Sensitivity Level (MSL)		1 (Unlimited)
REACH Status		REACH Affected
RoHS Status		ROHS3 Compliant

In Stock: 2000

Can ship immediately.
