ZVBP-1420-N+

ZVBP-1420-N+

Part Number	ZVBP-1420-N+
Manufacturer	Mini-Circuits
Other Part Numbers	3157-ZVBP-1420-N+-ND 3157-ZVBP-1420-N+
Description	RF FILTER BAND PASS 1.42GHZ MOD
Detailed Description	1.42GHz Center Frequency Band Pass RF Filter (Radio Frequency) 10MHz Bandwidth 2.5dB Module
Manufacturer Standard Lead Time	13 weeks
Datasheet	Datasheet

Product Attributes

Category		Filters RF Filters
Manufacturer		Mini-Circuits
Series		ZVBP-1420-N+
Packaging		Tray
Part Status		Active
Package / Case		Module
Filter Type		Band Pass
Size / Dimension		7.250" L x 1.425" W (184.15mm x 36.20mm)
Mounting Type		Chassis Mount
Frequency		1.42GHz Center
Insertion Loss		2.5dB
Bandwidth		10MHz
Height (Max)		2.725" (69.22mm)

Documents & Media

RESOURCE TYPE		LINK
Datasheets		ZVBP-1420-N+

Environmental & Export Classifications

ATTRIBUTE		DESCRIPTION
ECCN		EAR99
HTSUS		8548.00.0000
Moisture Sensitivity Level (MSL)		Not Applicable
RoHS Status		ROHS3 Compliant

In Stock: 8

Can ship immediately.
