Edgeboard Connectors

Mfr Part #	Quantity	Price	Series	Package	Product Status	Features	Gender	Contact Finish	Color	Mounting Type	Number of Positions	Pitch	Operating Temperature	Read Out	Contact Type	Card Type	Card Thickness	Flange Feature	Termination	Contact Finish Thickness	Material - Insulation	Contact Material	Number of Positions/Bay/Row	Number of Rows	Termination Rows
EBM06DREH CONN EDGE DUAL FMALE 12POS 0.156 Sullins Connector Solutions Datasheet	300 In Stock	1 : $5.20 10 : $47.20 30 : $134.10 40 : $174.80 80 : $332.80 230 : $837.20 440 : $1,557.60 950 : $2,869.00 2,400 : $6,744.00 Tray		Tray	Active	-	Female	Gold	Blue	Panel Mount	12	0.156" (3.96mm)	-65°C ~ 125°C	Dual	Full Bellows	Non Specified - Dual Edge	0.062" (1.57mm)	Top Mount Opening, Unthreaded, 0.125" (3.18mm) Dia	Solder Eyelet(s)	10.0µin (0.25µm)	Polybutylene Terephthalate (PBT)	Phosphor Bronze	6	2	-
EBC60DRXH CONN EDGE DUAL FML 120POS 0.100 Sullins Connector Solutions Datasheet	104 In Stock	1 : $12.51 10 : $110.90 30 : $319.80 40 : $409.60 80 : $773.60 230 : $2,026.30 440 : $3,630.00 950 : $7,182.00 Tray		Tray	Active	-	Female	Gold	Blue	Through Hole	120	0.100" (2.54mm)	-65°C ~ 125°C	Dual	Full Bellows	Non Specified - Dual Edge	0.062" (1.57mm)	Top Mount Opening, Unthreaded, 0.125" (3.18mm) Dia	Solder	10.0µin (0.25µm)	Polybutylene Terephthalate (PBT)	Phosphor Bronze	60	2	-
EBC20DRTH CONN EDGE DUAL FMALE 40POS 0.100 Sullins Connector Solutions Datasheet	11 In Stock	1 : $6.38 10 : $57.60 30 : $163.50 40 : $212.40 80 : $404.00 230 : $1,039.60 440 : $1,870.00 950 : $3,534.00 2,400 : $8,472.00 Tray		Tray	Active	-	Female	Gold	Blue	Through Hole	40	0.100" (2.54mm)	-65°C ~ 125°C	Dual	Full Bellows	Non Specified - Dual Edge	0.062" (1.57mm)	Top Mount Opening, Unthreaded, 0.125" (3.18mm) Dia	Solder	10.0µin (0.25µm)	Polybutylene Terephthalate (PBT)	Phosphor Bronze	20	2	-
EBC50DRXH CONN EDGE DUAL FML 100POS 0.100 Sullins Connector Solutions Datasheet	76 In Stock	1 : $11.36 10 : $102.20 30 : $288.90 40 : $375.20 80 : $731.20 230 : $1,874.50 440 : $3,370.40 950 : $6,431.50 Tray		Tray	Active	-	Female	Gold	Blue	Through Hole	100	0.100" (2.54mm)	-65°C ~ 125°C	Dual	Full Bellows	Non Specified - Dual Edge	0.062" (1.57mm)	Top Mount Opening, Unthreaded, 0.125" (3.18mm) Dia	Solder	10.0µin (0.25µm)	Polybutylene Terephthalate (PBT)	Phosphor Bronze	50	2	-
EBC10DRAS CONN EDGE DUAL FMALE 20POS 0.100 Sullins Connector Solutions Datasheet	2,447 In Stock	1 : $6.30 10 : $57.00 30 : $161.40 40 : $210.00 80 : $399.20 230 : $1,025.80 440 : $1,848.00 950 : $3,496.00 2,400 : $8,376.00 Tray		Tray	Active	-	Female	Gold	Blue	Through Hole, Right Angle	20	0.100" (2.54mm)	-65°C ~ 125°C	Dual	Full Bellows	Non Specified - Dual Edge	0.062" (1.57mm)	Side Mount Opening, Unthreaded, 0.125" (3.18mm) Dia	Solder	10.0µin (0.25µm)	Polybutylene Terephthalate (PBT)	Phosphor Bronze	10	2	-
EBC05DRAS CONN EDGE DUAL FMALE 10POS 0.100 Sullins Connector Solutions Datasheet	948 In Stock	1 : $5.08 10 : $46.10 30 : $130.80 40 : $170.40 80 : $324.80 230 : $816.50 440 : $1,518.00 950 : $2,793.00 2,400 : $6,576.00 Tray		Tray	Active	-	Female	Gold	Blue	Through Hole, Right Angle	10	0.100" (2.54mm)	-65°C ~ 125°C	Dual	Full Bellows	Non Specified - Dual Edge	0.062" (1.57mm)	Side Mount Opening, Unthreaded, 0.125" (3.18mm) Dia	Solder	10.0µin (0.25µm)	Polybutylene Terephthalate (PBT)	Phosphor Bronze	5	2	-
EBC05DRTH CONN EDGE DUAL FMALE 10POS 0.100 Sullins Connector Solutions Datasheet	1,351 In Stock	1 : $3.59 10 : $32.60 30 : $92.40 40 : $120.40 80 : $229.60 230 : $577.30 440 : $1,073.60 950 : $1,976.00 2,400 : $4,656.00 Tray		Tray	Active	-	Female	Gold	Blue	Through Hole	10	0.100" (2.54mm)	-65°C ~ 125°C	Dual	Full Bellows	Non Specified - Dual Edge	0.062" (1.57mm)	Top Mount Opening, Unthreaded, 0.125" (3.18mm) Dia	Solder	10.0µin (0.25µm)	Polybutylene Terephthalate (PBT)	Phosphor Bronze	5	2	-
EBM28DREH CONN EDGE DUAL FMALE 56POS 0.156 Sullins Connector Solutions Datasheet	600 In Stock	1 : $11.98 10 : $106.20 30 : $306.30 40 : $392.00 80 : $740.00 230 : $1,941.20 440 : $3,471.60 950 : $6,878.00 Tray		Tray	Active	-	Female	Gold	Blue	Panel Mount	56	0.156" (3.96mm)	-65°C ~ 125°C	Dual	Full Bellows	Non Specified - Dual Edge	0.062" (1.57mm)	Top Mount Opening, Unthreaded, 0.125" (3.18mm) Dia	Solder Eyelet(s)	10.0µin (0.25µm)	Polybutylene Terephthalate (PBT)	Phosphor Bronze	28	2	-
RBB60DHRN-S578 CONN PCI CARDEDGE FML 120P 0.050 Sullins Connector Solutions Datasheet	100 In Stock	1 : $17.14 10 : $148.50 30 : $422.40 50 : $693.50 100 : $1,224.00 250 : $2,857.50 500 : $5,590.00 Tube		Tube	Active	Card Extender	Female	Gold	Black	Board Edge, Straddle Mount	120	0.050" (1.27mm)	-65°C ~ 125°C	Dual	Hairpin Bellows	PCI 3.3V, 5V 32 Bit (Universal)	0.062" (1.57mm)	-	Solder	10.0µin (0.25µm)	Polyphenylene Sulfide (PPS)	Phosphor Bronze	11; 49	2	-
EBM18DRAS CONN EDGE DUAL FMALE 36POS 0.156 Sullins Connector Solutions Datasheet	192 In Stock	1 : $8.29 10 : $74.60 30 : $210.90 40 : $274.00 80 : $533.60 230 : $1,368.50 440 : $2,459.60 950 : $4,693.00 Tray		Tray	Active	-	Female	Gold	Blue	Through Hole, Right Angle	36	0.156" (3.96mm)	-65°C ~ 125°C	Dual	Full Bellows	Non Specified - Dual Edge	0.062" (1.57mm)	Side Mount Opening, Unthreaded, 0.125" (3.18mm) Dia	Solder	10.0µin (0.25µm)	Polybutylene Terephthalate (PBT)	Phosphor Bronze	18	2	-
