Pulse Transformers

Mfr Part #	Quantity	Price	Series	Package	Product Status	Inductance	Size / Dimension	Mounting Type	Operating Temperature	Transformer Type	Turns Ratio - Primary:Secondary	ET (Volt-Time)	Height - Seated (Max)	Grade	Qualification
T1137NL TRANSFORMER TELECOM DUAL T1/E2 Pulse Larsen Antenna Datasheet	600 In Stock	1 : $5.52 10 : $41.90 25 : $102.00 50 : $187.50 100 : $353.00 250 : $855.00 500 : $1,655.00 1,000 : $3,200.00 Tube		Tube	Active	1.2mH, 1.2mH	0.505" L x 0.280" W (12.83mm x 7.11mm)	Surface Mount	0°C ~ 70°C	T1/E1 (Dual)	1CT:2.42CT, 1CT:2.42CT	-	0.245" (6.22mm)	-	-
H5120NL MODULE XFORMR SNGL GIGABIT SMD Pulse Larsen Antenna Datasheet	1,012 In Stock	1 : $10.27 10 : $78.70 30 : $200.10 60 : $393.60 120 : $747.60 270 : $1,663.20 510 : $3,100.80 1,020 : $6,130.20 Tube		Tube	Active	-	0.650" L x 0.365" W (16.51mm x 9.27mm)	Surface Mount	0°C ~ 70°C	-	1CT:1CT	-	0.082" (2.08mm)	-	-
H5201NL MODULE XFORMR DUAL GIGABIT SMD Pulse Larsen Antenna Datasheet	204 In Stock	1 : $13.75 10 : $101.60 25 : $234.50 40 : $362.80 84 : $740.88 252 : $2,189.88 504 : $4,334.40 1,008 : $8,507.52 Tray		Tray	Active	-	0.580" L x 0.680" W (14.73mm x 17.27mm)	Surface Mount	0°C ~ 70°C	-	1CT:1CT	-	0.430" (10.92mm)	-	-
HX5400NL XFRMR MODL 4PORT POE GIGABIT Pulse Larsen Antenna Datasheet	200 In Stock	1 : $22.11 10 : $195.10 25 : $471.50 60 : $1,014.60 120 : $1,951.20 Tray		Tray	Active	350µH	1.120" L x 0.680" W (28.45mm x 17.27mm)	Surface Mount	-40°C ~ 85°C	Isolation and Data Interface (Encapsulated)	1CT:1CT Transmitter, 1CT:1CT Receiver	-	0.438" (11.12mm)	-	-
TX1089NL XFRMR 1CT:1CT/1CT:1CT 1.2/1.2MH Pulse Larsen Antenna Datasheet	390 In Stock	1 : $5.52 10 : $41.90 25 : $102.00 50 : $187.50 100 : $353.00 250 : $855.00 500 : $1,655.00 1,000 : $3,200.00 Tube		Tube	Active	1.2mH, 1.2mH	0.505" L x 0.280" W (12.83mm x 7.11mm)	Surface Mount	-40°C ~ 85°C	T1/E1 (Dual)	1CT:1CT, 1CT:1CT	-	0.245" (6.22mm)	-	-
PE-63387NL PULSE XFMR 1:1:1 1.5MH Pulse Larsen Antenna Datasheet	1,485 In Stock	1 : $10.09 10 : $77.30 30 : $196.50 60 : $386.40 90 : $550.80 240 : $1,454.40 450 : $2,686.50 960 : $5,673.60 Tray		Tray	Active	1.5mH	1.090" L x 0.750" W (27.69mm x 19.05mm)	Through Hole	0°C ~ 70°C	-	1:1:1	320VµS	1.200" (30.48mm)	-	-
H7029FNL 10GBASE-T DISCRETE 4CH MAR/SOL P Pulse Larsen Antenna Datasheet	1,455 In Stock	1 : $8.24 10 : $63.20 35 : $216.30 Tube		Tube	Active	120µH	0.539" L x 0.591" W (13.70mm x 15.00mm)	-	0°C ~ 70°C	LAN 10G Base-T	1:1	-	0.230" (5.85mm)	-	-
HD8004FNL PULSE XFMR 1CT:1CT TX 1CT:1CT RX Pulse Larsen Antenna Datasheet	315 In Stock	1 : $9.99 10 : $76.50 25 : $162.00 50 : $318.50 100 : $606.00 250 : $1,497.50 500 : $2,955.00 1,000 : $5,840.00 Tube		Tube	Active	180µH	0.539" L x 0.591" W (13.70mm x 15.00mm)	Surface Mount	0°C ~ 70°C	HDBase-T	1CT:1CT Transmitter, 1CT:1CT Receiver	-	0.225" (5.72mm)	-	-
PA2005NL PULSE XFMR 1:1:1 840UH Pulse Larsen Antenna Datasheet	10 In Stock	1 : $2.74 10 : $21.90 25 : $44.50 50 : $86.50 100 : $169.00 250 : $410.00 500 : $815.00 1,000 : $1,440.00 5,000 : $6,600.00 Tube		Tube	Active	840µH	0.340" L x 0.460" W (8.64mm x 11.68mm)	Surface Mount	-40°C ~ 130°C	-	1:1:1	26VµS	0.160" (4.06mm)	-	-
PA3855.002NL PULSE XFMR 48UH Pulse Larsen Antenna Datasheet	21 In Stock	1 : $4.22 10 : $34.20 25 : $69.00 60 : $155.40 120 : $296.40 240 : $576.00 480 : $1,118.40 960 : $2,160.00 Tray		Tray	Active	48µH	0.571" L x 0.695" W (14.50mm x 17.65mm)	Surface Mount	-40°C ~ 130°C	-	-	-	0.551" (14.00mm)	-	-
