Through Hole Resistors

Packaging

Bag

Box

Bulk

Cut Tape (CT)

Strip

Tape & Box (TB)

Tape & Reel (TR)

Tray

Tube

Product Status

Active

Obsolete

Discontinued

Not For New Designs

Number of Terminations

2

3

4

Failure Rate

M (1%)

P (0.1%)

R (0.01%)

S (0.001%)

Mfr Part #	Quantity	Price	Series	Package	Product Status	Power (Watts)	Tolerance	Features	Package / Case	Temperature Coefficient	Size / Dimension	Composition	Operating Temperature	Number of Terminations	Supplier Device Package	Height - Seated (Max)	Failure Rate	Resistance
AC05000008201JAC00 RES 8.2K OHM 5W 5% AXIAL Vishay BC Components Datasheet	2,794 In Stock	500 : $615.00 1,000 : $1,070.00 2,500 : $2,625.00 5,000 : $5,150.00 Tape & Box (TB)	AC	Cut Tape (CT) Tape & Box (TB)	Active	5W	±5%	Flame Retardant Coating, Pulse Withstanding, Safety	Axial	100/ +180ppm/°C	0.295" Dia x 0.709" L (7.50mm x 18.00mm)	Wirewound	-40°C ~ 275°C	2	Axial	-	-	8.2 kOhms
AC05AT0001002JAC00 RES 10K OHM 5% 5W AXIAL Vishay BC Components Datasheet	744 In Stock	500 : $560.00 Tape & Box (TB)	AC-AT	Cut Tape (CT) Tape & Box (TB)	Active	5W	±5%	Automotive AEC-Q200	Axial	100/ +180ppm/°C	0.295" Dia x 0.709" L (7.50mm x 18.00mm)	Wirewound	-55°C ~ 250°C	2	Axial	-	-	10 kOhms
AC07000008201JAC00 RES 8.2K OHM 7W 5% AXIAL Vishay BC Components Datasheet	1,484 In Stock	500 : $765.00 1,000 : $1,340.00 2,500 : $3,300.00 5,000 : $6,500.00 Tape & Box (TB)	AC	Cut Tape (CT) Tape & Box (TB)	Active	7W	±5%	Flame Retardant Coating, Pulse Withstanding, Safety	Axial	100/ +180ppm/°C	0.295" Dia x 1.024" L (7.50mm x 26.00mm)	Wirewound	-40°C ~ 275°C	2	Axial	-	-	8.2 kOhms
PAC500001002FAC000 RES 10K OHM 5W 1% AXIAL Vishay BC Components Datasheet	697 In Stock	500 : $730.00 1,000 : $1,260.00 2,500 : $3,100.00 5,000 : $6,100.00 Tape & Box (TB)	PAC	Cut Tape (CT) Tape & Box (TB)	Active	5W	±1%	Flame Retardant Coating, Pulse Withstanding, Safety	Axial	±100ppm/°C	0.295" Dia x 1.024" L (7.50mm x 26.00mm)	Wirewound	-55°C ~ 275°C	2	Axial	-	-	10 kOhms
G24071934709J7B000 RES 47 OHM 5% WW Vishay BC Components Datasheet	454 In Stock	250 : $287.50 500 : $480.00 750 : $675.00 1,250 : $1,037.50 2,500 : $2,050.00 6,250 : $5,062.50 12,500 : $9,875.00 Tape & Box (TB)	G200	Cut Tape (CT) Tape & Box (TB)	Active	7W	±5%	Flame Proof, Pulse Withstanding, Safety	Axial	100/ +180ppm/°C	0.335" Dia x 0.760" L (8.50mm x 19.30mm)	Wirewound	-55°C ~ 350°C	2	Axial	-	-	47 Ohms
G26093331000JLA000 RES 100 OHM 5% WW Vishay BC Components Datasheet	91 In Stock	1 : $8.90 10 : $79.30 25 : $194.50 50 : $343.00 100 : $563.00 300 : $1,611.00 500 : $2,500.00 1,000 : $4,630.00 Bulk	G200	Bulk	Active	13W	±5%	Flame Proof, Pulse Withstanding, Safety	Axial	100/ +180ppm/°C	0.386" Dia x 1.272" L (9.80mm x 32.30mm)	Wirewound	-55°C ~ 350°C	2	Axial	-	-	100 Ohms
G24071932201J7A000 RES 2.2K OHM 5% WW Vishay BC Components Datasheet	631 In Stock	100 : $121.00 300 : $327.00 500 : $455.00 1,000 : $790.00 2,500 : $1,925.00 5,000 : $3,800.00 10,000 : $7,500.00 Tape & Box (TB)	G200	Cut Tape (CT) Tape & Box (TB)	Active	7W	±5%	Flame Proof, Pulse Withstanding, Safety	Axial	100/ +180ppm/°C	0.335" Dia x 0.760" L (8.50mm x 19.30mm)	Wirewound	-55°C ~ 350°C	2	Axial	-	-	2.2 kOhms
AC05AT0006801JAC00 RES 6.8K OHM 5% 5W AXIAL Vishay BC Components Datasheet	1,000 In Stock	500 : $675.00 1,000 : $1,170.00 2,500 : $2,875.00 5,000 : $5,700.00 Tape & Box (TB)	AC-AT	Cut Tape (CT) Tape & Box (TB)	Active	5W	±5%	Automotive AEC-Q200	Axial	100/ +180ppm/°C	0.295" Dia x 0.709" L (7.50mm x 18.00mm)	Wirewound	-55°C ~ 250°C	2	Axial	-	-	6.8 kOhms
PAC300006809FAC000 RES 68 OHM 3W 1% AXIAL Vishay BC Components Datasheet	182 In Stock	1 : $1.01 10 : $8.50 25 : $20.50 50 : $37.50 100 : $61.00 Cut Tape (CT)	PAC	Cut Tape (CT) Tape & Box (TB)	Active	3W	±1%	Flame Retardant Coating, Pulse Withstanding, Safety	Axial	±100ppm/°C	0.217" Dia x 0.650" L (5.50mm x 16.50mm)	Wirewound	-55°C ~ 275°C	2	Axial	-	-	68 Ohms
AC05000001002JAC00 RES 10K OHM 5W 5% AXIAL Vishay BC Components Datasheet	2,823 In Stock	500 : $615.00 1,000 : $1,070.00 2,500 : $2,625.00 5,000 : $5,150.00 Tape & Box (TB)	AC	Cut Tape (CT) Tape & Box (TB)	Active	5W	±5%	Flame Retardant Coating, Pulse Withstanding, Safety	Axial	100/ +180ppm/°C	0.295" Dia x 0.709" L (7.50mm x 18.00mm)	Wirewound	-40°C ~ 275°C	2	Axial	-	-	10 kOhms
